Overview

PENTA LASER BOLT CUBE is the high-precision core cutting unit of 3D 5-axis cutting automation line, specialized in high-precision processing of complex 3D workpieces. As the core component of the automation line, it integrates 5-axis linkage and high-rigidity structure, and works with automatic loading/unloading, intelligent control and scheduling systems to form a closed-loop production line. Widely used in high-end manufacturing, it ensures cutting accuracy and efficiency, helping the automation line shorten cycles, reduce labor and secondary processing costs.

What Is BOLT CUBE? (Core Cutting Unit of 3D 5-Axis Automation Line)

BOLT CUBE (models 3015/4023) is PENTA LASER’s professional 5-axis cutting unit, serving as the core component of 3D 5-axis cutting automation line. It is a high-precision 5-axis linkage cutting machine, which matches with the automation line’s automatic loading/unloading robot, dual-station rotary table and Smart Manager control system to realize fully automated, unmanned continuous production of complex workpieces.

Core positioning:

• Core cutting unit of 3D 5-axis automation line

• High-precision 5-axis cutting for complex 3D workpieces

• Stable performance for batch cutting

• Seamless matching with automation line systems

Core Advantages of BOLT CUBE (Core Cutting Unit)

1. High-Precision 5-Axis Linkage, Stable Batch Cutting

• 5-axis linkage with RTCP calibration ensures laser perpendicularity to cutting surface, no dead zones, and consistent batch edge quality.

• Linear axis positioning accuracy ±0.1mm, rotation axis repeat accuracy ±0.01°, meeting high-precision batch processing needs.

• Dynamic focus compensation ensures consistent cutting quality for all batch workpieces.

2. High Cutting Efficiency, Matching Automation Line

• Linear axis speed up to 100m/min, matching the automation line’s rhythm, realizing synchronous processing and loading/unloading.

• Efficiency increased by 60%+ vs traditional 3-axis cutting machines, boosting the overall efficiency of the automation line.

• One-time clamping completes multi-angle cutting, reducing clamping errors and matching the automation line’s unmanned production.

3. Intelligent Control, Seamless Integration with Automation Line

• Smart Manager system + Smart 3D Pro software supports CAD/CAM import, 3D simulation, matching the automation line’s intelligent control.

• Real-time cutting data feedback, integrating with the automation line’s monitoring system for unified management.

• Intelligent detection function, ensuring cutting quality and matching the automation line’s quality control.

4. Stable Structure, Adaptable to Automation Line Continuous Operation

• High-rigidity frame suppresses vibration, ensuring stable operation and matching the automation line’s long-term continuous production.

• Multi-level safety protection, integrating with the automation line’s safety system to ensure overall safety.

• 1-6kW optional fiber laser, low energy consumption and maintenance cost, suitable for the automation line’s continuous operation.

Application of BOLT CUBE in Automation Line

• Automotive automation line:Core cutting unit for batch cutting of hot-formed parts, battery trays.

• Aerospace automation line:Precision cutting unit for irregular curved parts and high-strength alloy parts.

• Mold automation line:Core cutting unit for batch cutting of mold cavities and complex parts.

• New energy automation line:Cutting unit for batch processing of equipment casings and core components.

• General manufacturing automation line:Core cutting unit for complex 3D parts batch processing.

Why Choose BOLT CUBE as the Core Cutting Unit?

• PENTA LASER:Global leading brand with CE/ISO certifications, professional 5-axis cutting technology.

• Customizable:Laser power and processing range available, matching different automation line needs.

• Seamless integration:Native compatibility with PENTA LASER automation line systems, ensuring stable operation.

• High cost-performance:Low energy consumption and maintenance cost, boosting automation line efficiency.

• Future-oriented:Supports AI optimization and Industry 4.0 connectivity, adapting to intelligent automation line upgrading.
