BOLT VII PRO+PLA COMPACT
BOLT VII PRO+PLA COMPACT
Penta Laser BOLT VII PRO + PLA COMPACT is a high-performance, fully automatic laser cutting loading and unloading system, offering advantages such as high precision, high stability, intelligence, and robust safety protection. It is ideal for the automated processing of medium and thick carbon steel plates, significantly enhancing production efficiency and product consistency. This system is suited for high-end manufacturing sectors, including heavy industry, rail transit, and engineering machinery.
Product Details
Characteristics
· Compact design (height ≤ 3.6m) with quick-mount supports; installation within 2-3 days.
· Loading robot features sheet separation detection, in-motion detachment detection, and sheet drop detection.
· Unloading robot equipped with unloading collision detection.
· Finished table includes material stopper; full-perimeter safety guard ensures operational safety.
· Self-developed central control system automatically coordinates cutter and automation, auto-schedules production based on work orders to boost planning and execution efficiency.
Technical Parameters
|
Model |
PLA - Compact (3015) |
|
Plate Thickness Range (mm) |
0.8 - 25 |
|
Raw Material |
Carbon Steel |
|
Applicable Maximum Size (mm) |
3048 × 1024 |
|
Applicable Minimum Sheet Size (mm) |
800 × 800 |
|
Maximum Weight for Manipulator Loading and Unloading (kg) |
800 |
|
Load Capacity of Raw Material Cart (t) |
3 |
|
Load Capacity of Finished Product Cart (t) |
3 |
|
Maximum Loading Height of Raw Material Layer (mm) |
250 (including wooden pallet) |
|
Horizontal Travel Speed (m / min) |
40 |
|
Vertical Lifting Speed (m / min) |
15 |
*Some technical specifications may vary due to physical constraints related to the dimensions of the machine
Applications
 |  |  |  |  |
|
Construction Machinery
|
Steel Structures
|
Rail Transit
|
Sheet Metal Processing
|
Shipbuilding
|
