Three-Axis Positioning Robot Welding Platform

Penta Laser Three-Axis Positioning Robot Welding Platform integrates a three-axis positioner with a two-layer platform design, occupying a small footprint with a compact layout. It is capable of fulfilling multi-trajectory and multi-station welding demands in industries such as automotive, shipbuilding, and new energy. The system ensures fully enclosed safety protection while efficiently completing complex operations.

Inquiry

Product Details

Characteristics

· Six-axis robot for continuous long-duration welding; three-axis positioner allows multi-angle, multi-position welding for higher efficiency.

· Laser safety enclosure effectively blocks radiation and protects operators.

· A two-level platform design saves space with a compact layout.

· Supports laser welding, print welding, and laser hybrid processes.

Optional Configurations

Welding Rotary Positioner

Automatic Visual Positioning Calibration

*Some technical specifications mayvarydue to physical constraints relatedto the dimensions of the machin

Technical Parameters

Model	RW 1510P
Equipment Dimensions (mm)	6000 × 3500 × 3000
Air Supply (MPa)	0.5 - 0.7
Power Supply (Hz)	380VAC, 50
Laser Type	FFRC - H, FFRC - SM, FFRQ, FFRSC
Laser Power (W)	300 - 6000
Welding Head Type	Collimator Head, Swing Head, Composite Head
Welding Dimensions (mm)	1500 × 1000 × 400

Applications


Automotive Parts	Hardware	Shipbuilding	New Enetrgy Sector
